Bespoke Lighting Solutions
OUR SERVICES
TECHNICAL EXPERTISE
Our professional team of specialists offer on-site consultation to advise and help you in specifying the very best products you need to bring your project to reality.
BESPOKE SOLUTIONS
We offer bespoke LED solutions, for any project large or small, including a professional tailor-made service for linear flex and suspendable linear LED fixtures.
DIALUX LIGHTING DESIGN
For projects which require more technical information including lux levels, we have full photometric data (IES files) for all our products and we offer a free DIALux lighting report and design service.
| Series | |||
|---|---|---|---|
|
OUR SERVICES - Bespoke Lighting Solutions | ||
|
|
OUR SERVICES - Bespoke Lighting Solutions | ||
|
OUR SERVICES - Bespoke Lighting Solutions | ||
|
OUR SERVICES - Bespoke Lighting Solutions | ||
|
OUR SERVICES - Bespoke Lighting Solutions | ||
|
OUR SERVICES - Bespoke Lighting Solutions |
| Option | Part Number | ||
|---|---|---|---|
|
|
White Light, Black Housing - Spread | 2LT 980 740-001 | |
|
|
White Light, White Housing - Spread | 2LT 980 740-011 | |
|
|
White Light, Black Housing - Spot | 2LT 980 740-201 | |
|
|
White Light, White Housing - Spot | 2LT 980 740-211 |
| Housing description | ‘Non metal’ thermally conductive polymer housing |
| Lens material | Grilamid |
| Bracket | Polished 316 stainless steel |
| Colour temperature | 5000K (White) |
| Cable | Pre-wired with 2.5m of triple core marine cable |
| Operating Voltage | Multivolt? 9-33V DC |
| Degree of Protection | IP 67 - Completely Sealed |
| High Power Consumption | 18W (<1.5A@12V / <0.75A@24V) |
| Low Power Consumption | 2W (<0.17A@12V / <0.08A@24V) |
| Weight | 450g (including cable) |
| Light Output | 1500 lumens (White) |
| Approvals | CE, RCM |
| Manufactured in | New Zealand |
